Steel Aluminum Zinc Alloy Metal Molds

一、Process Flow

Design

The production of casting molds begins with precise design. Engineers use CAD software for three-dimensional modeling, planning key elements such as the structure and parting surface of the Casting Mold . When designing Precision Casting Mold, the focus is on maintaining accuracy and ensuring the feasibility of demolding, to ensure that the castings meet strict standards.

Material Processing

Precise cutting is carried out using Laser Cutting Service. Complex mold structures are processed through CNC Milling and 5-Axis CNC Milling. For shaft parts, CNC Turning is used to ensure accuracy and smoothness.

Assembly & Debugging

The assembly is carried out using Sheet Metal Welding Service and Metal Welding Service. The mold is tested through Aluminum Die Casting and the parameters are optimized until the mold performance meets the standards.

二、Equipment Capabilities

Processing Equipment

The company is equipped with multi-axis CNC machining centers, which meet the requirements of Metal Milling Service. They can process small Aluminum Casting Molds and large Metal Casting Molds. The Laser Cutting equipment has an accuracy of ±0.1mm and is suitable for processing mold components.

Testing Equipment

A three-coordinate measuring instrument (with micrometer-level accuracy) ensures the quality of Precision Casting Mold. A metallographic microscope and a hardness tester are used for material structure analysis and hardness testing respectively, to guarantee the performance of the mold.
